    Nk15 Nk12 Solid Needle Roller Bearingss Single Row RNA 4906 Without Inner Ring

    Ask Lasest Price
    Brand Name : MOUETTE
    Model Number : NK06/10TN, NK08/12, NK10/10, NK15/12, NK16/20, NK18/20, NK20/16, NK25/16, RNA4901, RNA4903, RNA4904, RNA6901, RNA6903, RNA6904, RNA5903, NKS25, NKS30, NKS32
    Certification : ISO/TS 16949:2009, ISO 9001:2008
    Price : USD1 per Piece (Inquired for details)
    Payment Terms : L/C, T/T, D/A, Western Union, Paypal
    Supply Ability : 500,000 Pieces per Month.
    Delivery Time : 3-45 working days.(Huge Quantity Stocks Available))
    • Product Details
    • Company Profile

    Nk15 Nk12 Solid Needle Roller Bearingss Single Row RNA 4906 Without Inner Ring

    Solid Collar Needle Roller Bearings Without Inner Ring NK15/12 RNA4906

    Single row needle roller bearing with machined rings, with flanges, without inner ring

    Single row needle roller bearings without an inner ring consist of an outer ring with a needle roller and cage assembly. They are an excellent choice for compact bearing arrangements in applications where hardened and ground raceways can be provided on the shaft. The outer ring includes two integral flanges to guide the bearing axially and an annular groove with one or more lubrication holes to facilitate relubrication.

    • High radial load carrying capacity
    • High stiffness
    • Low cross-sectional height
    • Accommodate axial displacement in both directions

    Solid Collar Needle Roller Bearings Without Inner Ring Specifications:

    Shaft

    Dia-meter

    Bearing Designation

    Mass

    Approx

    Boundary Dimensions Basic Load Rating Limiting Speed
    Current Code Original Code Fw D C Dynamic Static Oil
    mm g mm N rpm
    5 NK5/10TN 2.9 5 10 10 2100 1400 36780
    NK05/08 5 10 8
    NK05/10TN-OH 5 10 12 2350 1920 39000
    NK05/12TN 3.7 5 10 12 3000 2650 39000
    6 NK06/10 6 12 10 2600 2200 37000
    NK06/10TN 6 12 10 2600 2200 37000
    NK06/12TN 5.7 6 12 12 3350 3150 37000
    RNA6X13X8TN 6 13 8
    7 NK07/10 6.9 7 14 10 2850 2650 34000
    NK07/12 8.2 7 14 12 3650 3600 34000
    7.8 RNA7.8169 7.8 16 9
    8 NK08/12TN 8.3 8 15 12 3950 4100 32000
    NK08/12 8.7 8 15 12 3950 4100 32000
    NK08/16 12 8 15 16 5100 5800 32000
    NK08/16TN 8 15 16 5100 5800 32000
    RNA8X19X9 8 19 9
    RN8X14X8 8 14 8
    RNA496 8 15 10
    RNA8X15X10TN 8 15 10
    9 NK09/12 10.3 9 16 12
    10 NK10/12TN 462409K 10 10 17 12 4750 5300 29000
    5624097 16.6 10 17 15 4860 7100 29000
    NK10/10 10 17 10
    NK10/12 10 17 12
    NK10/16 10 17 16 6200 7800 29000
    NK10/16TN 10 17 16 6200 7800 29000
    NKS10 10 19 13 5800 6000 29000
    12 NK12/12TN 644097 11.8 12 19 12 6000 6400 27000
    5624098 15.4 12 19 15 6400 7100 27000
    NK12/16 16.8 12 19 16 8200 9800 27000
    14 NK14/16 4624900K 20.8 14 22 16 10100 11500 25000
    NKS14 27 14 25 16 1400 13800 24000
    RNA4900 4624900 24.4 14 22 13 8500 9000 25000
    RNA6900 6634900 29.1 14 22 22 12800 15600 25000
    NK14/12 14 22 12
    NK14/20 14 22 20 12800 15600 25000
    15 NK15/12 644800K 18.5 15 23 12 8600 11000 21000
    RNA152815 31.7 15 28 15 13600 17200 24000
    7948/15 16.1 15 22 12 8200 9800 8500
    15 644302 18.2 15 25 12 10600 13500 17000
    NK15/16 21.8 15 23 16 10700 12700 24000
    NK15/20 26.7 15 23 20 13600 17200 24000
    NK152312 15 23 12
    NK152512 15 25 12
    16 NK16/16 20.8 16 24 16 11300 13900 23000
    NK16/20 624701 23.9 16 24 20 10400 16800 23000
    RNA4901 4624901 16.6 16 24 13 6400 8900 15500
    RNA6901 6634901 28.7 16 24 22 14000 18600 15500
    NKS16 30 16 28 16 14900 15000 20000
    NK162516 16 25 16
    NK162616 16 26 16
    17 NK17/16 644903K 21.5 17 25 16 9000 13500 14000
    NK17/20 RNA172520 30 17 25 20 15000 20000 23000
    18 NK18/20 30.5 18 26 20 15500 19800 22000
    NK18/16 18 26 16 12500 16200 22000
    19 NK19/16 19 27 16 13000 17000 22000
    20 NK20/16 644802 25.7 20 28 16 10500 13800 21000
    NK20/20 624802 29.3 20 28 20 11500 21800 21000
    NK202616 20.8 20 26 16 9600 10800 21000
    NK202620 20 26 20 9600 10800 21000
    NKS20 46.8 20 32 20 20000 23000 20000
    NK203312SX 29.1 20 33 12 13000 18000 11000
    6624101 24.3 20 28 25 13000 17500 11000
    RNA4902 4624902 20.5 20 28 13 11000 12900 12000
    RNA6902 6634902 35.4 20 28 23 10800 12800 12000
    NK20/16 20 32 16 13000 25000 12000
    RNA5902 20 28 18
    21 NK21/12 21 29 12
    NK21/16 21 29 16 13500 18700 21000
    NK21/20 21 29 20
    22 NK22/16 NK223016 29.2 22 30 16 13500 18000 11500
    NK223516 34.6 22 35 16 18600 20800 11500
    NKS22 60.2 22 35 20 21500 25000 17000
    RNA4903 4644903 20.7 22 30 13 12000 16800 16300
    RNA5903 22 30 18
    RNA6903 6634903 39.8 22 30 23 14000 19900 16300
    624703 53 22 35 25 24500 28000 14100
    634704L 42.5 22 30 30 17700 27000

    16500

    22

    644704 27.4 22 28 16 10500 15000 16500
    NK223516 49.4 22 35 16 18600 20800 16500
    NK22/20 22 30 20
    23 634704KA 37.5 23 30 30 18600 29000 15000
    24 NK24/16 24 32 16
    NK24 X 33.5 X 7.5 24 33.5 7.5
    25 NK25/16 624904 30 25 33 16 12900 20400 15000
    NK25/20 644804 38.4 25 33 20 16800 28500 15000
    RNA4904 4644904 50.8 25 37 17 11900 16500 15000
    RNA6904 6634904 97.7 25 37 30 26000 43000 15000
    NKS25 65 25 38 20 25800 31000 16300
    624704 100.1 25 35 25 14900 22400 16500
    NK25/30 644804K 63 25 33 30 18800 30500 165000
    NK253326 25 33 26
    NK253422 25 34 22
    NK253425 25 34 25
    NK253820 25 38 20
    NK253825 25 38 25
    NK254517.5 25 45 17.5
    26 NK26/16 30 26 34 16 15000 23000 16300
    NK26/20 40 26 34 20 17000 30000 16300
    27 NK27 X 40 X 25 27 40 25
    28 RNA283833 99.8 28 38 33 33000 57000 12000
    F3833 99.8 28 38 33 33000 57000 12000
    NKS28 80 28 42 20 25900 33500 15000
    NK28/20 53 28 37 20 22000 34000 16500
    NK28/30 28 37 30 33000 57000 12000
    RNA69/22 63549/22 28 39 30
    29 NK29/20 29 38 20 21900 34000 15000
    NK29/30 29 38 30 32500 57000 15000
    30 NK30/20 644805 57.9 30 40 20 20600 32000 15000
    NK30/30 95 30 40 30 31500 50000 15000
    RNA4905 4624905 57 30 42 17 23600 31500 14000
    RNA6905 6634905 106.5 30 42 30 39000 59000 14000
    624905 68 30 42 20 20000 32000 15000
    NK304013 30 40 13
    NK304430 30 44 30
    NK304630 30 46 30
    NK305017 30 50 17
    30 NKS30 30 45 17 32000 40000 14000
    RNA305225 30 52 25
    30.5 NK30.5 X 50 X 16 30.5 50 16
    NK30.5 X 50 X 17 30.5 50 17
    31 NK31.75 X 44.45 X 31.75 31.75 44.45 22
    32 NK32/20 624705 75.4 32 42 20 22600 33500 15000
    RNA49/28 46449/28K 80 32 45 17 17400 30000 13000
    NAS32 100 32 47 22 31000 40000 13000
    RNA69/28 125 32 45 30 39500 61300 13000
    644906 42 32 38 11 10750 30500 12000
    644706 193 32 50 35 40500 63000 12000
    NKS32 100 32 47 22 31000 40000 12000
    NK32/30 32 42 30 33500 60000 12000
    RNA324527 32 45 27
    34 NK345034 34 50 34
    NK345035 34 50 35
    35 NK35/20 644806 70 35 45 20 13800 26900 12000
    RNA4906 4624906 62.8 35 47 17 17000 30500 12000
    RNA6906 6634906 116 35 47 30 35000 67000 12000
    644907 161 35 51 43500 71000 12000
    NK354512 35 45 12
    NK354830 35 48 30
    NK355034 35 50 34
    NK355236 35 52 36
    RNA354527 35 45 27
    RNA5906 108 35 47 23
    RNA355730 35 57 30
    RNA355734 35 57 34
